PlantUML is not directly supported by GitHub, but its still possible. Basically we pass your puml file to PlantUML to generate, and they return a PNG which gets included in the page
- Generate you .puml file in the usual way using your favorite editor and confirm the diagram is as you want it.
- Save the file to the assets directory
- Then paste the following into you Markup.
PlantUML is a text descriptive language which gets converted into UML and other types of graphs So this :-
would produce this :-
A more complex example :-
