I found a good resource, so I can include bot C4 diagrams and Azure icons within a PlantUML diagram. I’ve done C4 within PlantUml before but it was a bit crude.

![C4 flowchart](http://www.plantuml.com/plantuml/proxy?cache=no&src=https://raw.github.com/newportg/newportg.github.io/master/assets/C4/c4.puml)

C4 flowchart
![Azure flowchart](http://www.plantuml.com/plantuml/proxy?cache=no&src=https://raw.github.com/newportg/newportg.github.io/master/assets/C4/azure.puml)

Azure flowchart

https://github.com/RicardoNiepel/Azure-PlantUML
